Ceramic Fiber Board
Ceramic Fiber Board - Image 2

Ceramic Fiber Board

Refractory Fiber Board is manufactured by blending various refractory fibers with inorganic binders and a small amount of organic binders in specific proportions. Its service temperature ranges from 1000°C to 1800°C.
Featuring superior high-temperature stability, excellent thermal shock resistance and corrosion resistance, the product also boasts low heat capacity and low thermal conductivity. Thanks to its rigid texture and high internal bonding strength, it can be easily machined and cut. It is flame-contact resistant, simple to install and apply.
ITEM 1260 1260 Board 1400 Board 1500 Board 1500 Board
Board
Working Temperature ℃ 1100 1100 1300 1400 1400
Density  kg/m³ 250 300 300 300 400
Line Shrinkage (%)*8h 2.5 1.8 1.6 0.6 0.5
(1100℃) (1100℃) (1200℃) (1400℃) (1400℃)
Thermal Conductivity at 400℃ 0.13 0.12
(w/m・k) at 600℃ 0.17 0.16 0.12 0.12 0.11
at 800℃ 0.24 0.23 0.15 0.17 0.15
at 1000℃ 0.25 0.22 0.21
Chemical Composition(%) Al₂O₃ 43 43 45 62 62
Al₂O₃ + SiO₂ 98 98 98 98 98
Grade Density (kg/m³) L*W mm Standard Thickness mm Packing
1260 250 300 350 1200*1000 25 30 40 50 60 70 80 Pallet Carton
1000*600 25 30 40 50 60 70 80
1400 250 300 350 1200*1000 25 30 40 50 60 70 80
1000*600 25 30 40 50 60 70 80
1500 300 350 400 1000*600 25 40 50 60 70 80
